Bernina 700 - User Manual

Other manuals for Bernina 700

User Manual132 pages

Questions and Answers

A
andreavasquezAug 18, 2025
Why is my Bernina Sewing Machine skipping stitches?
- V
  Vanessa BrownAug 18, 2025
  If your Bernina Sewing Machine is skipping stitches, there are a few potential causes. First, ensure you are using the correct needle system 130/705H. A blunt or bent needle can also cause skipped stitches, so replace the needle if necessary. Using a new BERNINA quality needle is also important. Check that the needle is correctly inserted with the flat side to the back, as far up as it will go into the needle holder, and that the screw is tightened. Finally, make sure the needle point matches the texture of the material you are sewing.
C
Christian HamptonAug 20, 2025
How to fix uneven stitch formation on my Bernina 700 Sewing Machine?
- C
  Corey ButlerAug 20, 2025
  If you're experiencing uneven stitch formation with your Bernina Sewing Machine, it might be due to several reasons. The upper thread could be too tight or too loose, so try adjusting the upper thread tension. The needle might be blunt or bent, in which case you should replace it with a new BERNINA quality needle. It could also be due to a poor quality needle or thread, so ensure you're using quality materials. Check that the needle and thread combination are correct, and that the machine is correctly threaded. Finally, make sure you are using the supplied bobbin case with triangles.
J
Jodi SmithAug 23, 2025
What to do if upper thread breaks on my Bernina 700 Sewing Machine?
- M
  melanie61Aug 23, 2025
  If the upper thread of your Bernina Sewing Machine is breaking, several factors could be the cause. Ensure that you're using the correct needle and thread combination. If the upper thread is too tight, reduce the upper thread tension. Make sure the machine is correctly threaded and that you are using quality thread. If the stitch plate or the hook tip is damaged, contact the nearest specialized BERNINA dealer to have the damages repaired. Also, check if the thread is caught in the area of the thread take-up lever; if so, remove the screw on the headframe with the angular Torx wrench, pull the headframe slightly forward at the bottom, flip it upwards a bit, and remove it to clear any thread remnants. Then, reattach the headframe and tighten the screw.
M
medinamatthewAug 26, 2025
How to resolve faulty stitching on my Bernina Sewing Machine?
- G
  ghughesAug 26, 2025
  If you're experiencing faulty stitching on your Bernina Sewing Machine, it could be due to a few reasons. There might be thread remnants between the thread tension discs; to resolve this, fold a piece of thin material and slide the folded edge between the thread tension discs. Ensure the machine is correctly threaded. Also, check for thread remnants below the bobbin case spring and remove them if present.
M
Melissa KimAug 28, 2025
Why does the lower thread break on my Bernina 700?
- B
  brittanybutlerAug 28, 2025
  If the lower thread is breaking on your Bernina Sewing Machine, it could be due to a damaged bobbin case, so replace it. Another cause might be a damaged stitch hole in the stitch plate, in which case you should contact the nearest specialized BERNINA dealer to have the damages repaired. Also, a blunt or bent needle can cause the lower thread to break, so replace the needle.
J
James SpencerAug 30, 2025
What to do if my Bernina 700 doesn't start?
- S
  Sue MckinneyAug 30, 2025
  If your Bernina Sewing Machine isn't starting, it could be due to an unfavorable room temperature. Place the machine in a warm room one hour before use and ensure it is connected and switched on. If that doesn't solve the issue, the machine might be damaged, in which case you should contact the specialized BERNINA dealer.
T
Trevor WebbSep 1, 2025
How to fix error during software update on Bernina 700 Sewing Machine?
- K
  Kathryn WilliamsSep 2, 2025
  To resolve an error during a software update on your Bernina Sewing Machine, ensure you are using a BERNINA USB stick. If the update process is blocked and the hourglass on the display is inactive, remove the USB stick, switch the machine off, then switch it back on, and follow the instructions on the display. If the date of the software update cannot be found, unzip the update data and save the software update data directly on the data medium, not in a file on the USB stick.
V
Valerie GutierrezSep 4, 2025
What causes needle breaks on a Bernina 700 Sewing Machine?
- B
  Bradley GonzalesSep 4, 2025
  If the needle is breaking on your Bernina Sewing Machine, ensure that the needle is correctly inserted with the flat side to the back, as far up as it will go into the needle holder, and that the screw is tightened. Also, knotted thread can cause the needle to break, so use quality thread.
D
dixontimothySep 6, 2025
What to do if the display is inactive on my Bernina 700 Sewing Machine?
- E
  ericblairSep 7, 2025
  If the display on your Bernina Sewing Machine is inactive, it could be due to incorrect calibrating data. To fix this, switch the machine off, then switch it back on while simultaneously pressing and holding the «SET» and «Center of the embroidery motif» buttons to re-calibrate the display. Alternatively, the eco-function might be active; touch the «eco-Mode» icon to deactivate it.
C
Carrie ThompsonSep 9, 2025
Why is the speed too low on my Bernina 700 Sewing Machine?
- C
  Carol GillSep 9, 2025
  If your Bernina Sewing Machine's speed is too low, it could be due to an unfavorable room temperature. Place the machine in a warm room one hour before use. It could also be due to settings in the Setup Program, so adjust the sewing speed in the Setup Program and adjust the slide.

Summary

Safety and Important Information

Essential Safety Instructions

Critical safety guidelines to prevent hazards like electric shock, burns, and injuries.

Important Machine Information

Details on manual availability, appropriate use, servicing, and environmental protection.

BERNINA 700 Introduction and Components

Machine Overview and Controls

Identifies controls and parts on the front, side, and back of the machine.

Embroidery Module Components

Identifies and labels components of the embroidery module.

Supplied Accessories

Machine Accessories

Lists and describes standard machine accessories like covers and boxes.

Embroidery Module Accessories

Lists and describes accessories for the embroidery module.

User Interface and Basic Operations

User Interface Navigation and Views

Details the machine's user interface, functions, and settings menus.

Needle, Thread, and Fabric Basics

Guidance on selecting appropriate needles and threads for embroidery.

Embroidery Preparation Steps

Step-by-step guide for preparing the machine and materials for embroidery.

Machine Setup and Customization

Embroidery Settings Configuration

Adjusting settings like thread tension, speed, and motif placement.

Machine Settings Customization

Customizing language, display brightness, and other machine parameters.

Creative Embroidery Operations

Editing and Manipulating Embroidery Motifs

Covers scaling, moving, rotating, mirroring, and altering embroidery motifs.

Creating Lettering and Text Designs

Guide to creating and editing words, sentences, and text designs.

Managing Embroidery Motifs

Instructions for saving, loading, overwriting, and deleting embroidery motifs.

Machine Maintenance and Troubleshooting

Routine Cleaning Procedures

Instructions for cleaning the display, hook, and thread catcher.

Troubleshooting Common Issues

Lists common failures, causes, and repair steps for stitch and thread issues.

Error Messages and Solutions

Explains error messages and provides solutions for various machine problems.

Embroidery Motifs Catalog

Embroidery Motifs Library Overview

A catalog of various embroidery motifs, categorized by type.

Quilt and Decorative Motifs

A selection of quilting and decorative designs available for embroidery.

Monogram Collections

Collection of alphabetic monograms for personalized embroidery.

Bernina 700 Specifications

General

Embroidery Designs	320
Color Touch Screen	Yes
USB Interface	Yes
Thread Cutter	Automatic
LED Sewing Light	Yes
Maximum Embroidery Area	400 x 210 mm
Embroidery Alphabets	18
Touchscreen	Yes
Thread Tension	Adaptive Thread Tension
Bernina Hook System	Yes
Connectivity	USB
Automatic Needle Threader	Yes
Speed Control	Yes
LCD Screen	Color Touch Screen
Maximum Embroidery Speed	1000 stitches per minute
Type	Embroidery Machine
Stitch Width	9 mm
