Berthold Duo Xpert - Page 33

LB 470 Level 4 Installation
56925BA2 Rev. 03, 11/2017
33
Installation of the modules (master-master)
1
2
3
4
Master-slave connector
Socket board
Guide rails
Fixing screws
Fig.
16 Installation of the modules (master-master)
1. Set modules into the guide rails and push it gently until the plug connector
of the module (
Fig. 16, item 2) is inserted into the socket board.
2. Tighten all fixing screws (Fig. 16, item 4).
