4 Installation LB 470 Level
56925BA2 Rev. 03, 11/2017
Mounting the wall housing
4 holes (Fig. 17) are provided for mounting on the wall etc.
17 Mounting the wall housing
1. Prepare the holes.
2. Use adequately dimensioned mounting material.
3. Screw the housing securely to the wall.
It is recommended that the wall housing be protected from direct sunlight in
order to maintain maximum ambient temperature (see appendix “Technical
Information”).
