16.1 Defining the display range
To define the sampling rate, go to Menu > Measurement chart > Settings > Display range
Fixed value
08.03.2015 05:05:06
Submenu “Display range”
(The “Object temperature” menu item is visible only
with optional chamber equipment)
Select the desired parameter
and press the operating button.
Display range
Temperature
Object temperature
Close Home
Fixed value
08.03.2015 05:05:06
Entry menu “Enter minimum value”.
Enter the desired value for temperature with the
operating button and press the operating button to
confirm.
..\ Enter minimum value
2
0.00
[°C]
2
Pos1 End Ok 0 1 3 4 5 6 7 8 9 . -
Close Ok Home
Fixed value
08.03.2015 05:05:06
Entry menu “Enter maximum value”.
Enter the desired value for temperature with the
operating button and press the operating button to
confirm.
..\ Enter maximum value
4
5.00
[°C]
4
End Ok 0 1 2 3 5 6 7 8 9 . - Del
Close Ok Home
You can now define the view range of other parameters or press the “Close” button twice to go back to
the graphic display.
