KB (E4 + E6) 02/2017 page 127/148
Message “Sensor rupture”
Sensor rupture between sensor
and controller or Pt100 sensor
Contact BINDER service.
No controller operation
possible.
Notification
Key lock activated.
Enter the key lock password (chap.
11).
Only qualified service personnel authorized by BINDER must perform repair.
Repaired chambers must comply with the BINDER quality standards.
23. Technical description
23.1 Factory calibration and adjustment
This chamber was calibrated and adjusted in the factory. Calibration and adjustment were performed
using standardized test instructions, according to the QM DIN EN ISO 9001 system applied by BINDER
(certified since December 1996 by TÜV CERT). All test equipment used is subject to the administration of
measurement and test equipment that is also constituent part of the BINDER QM DIN EN ISO 9001 sys-
tems. They are controlled and calibrated to a DKD-Standard at regular intervals.
Repeated calibrations are recommended in periods of 12 months.
23.2 Over current protection
The chambers are equipped with an internal fuse (over-current release) not accessible from outside. If
this fuse is blown, please contact an electronic engineer or BINDER Service.
In addition, the chambers KB 53-UL / 115-UL are protected by a chamber-protection against over cur-
rent, accessible from the outside. It is located at the rear of the chamber below the strain relief of the
power cord. The fuse holder is equipped with a fuse clip 6.3 x32 mm. Replace this fuse only with a substi-
tute of the same ratings. Refer to the technical data of the respective device type. If this fuse is blown,
please inform an electronic engineer or BINDER service.
