KB (E4 + E6) 02/2017 page 112/148
19. Options
19.1 Communication software APT-COM™ 3 DataControlSystem (option)
The chamber is regularly equipped with an Ethernet interface (7) that can connect the BINDER communi-
cation software APT-COM™ 3 DataControlSystem. The MAC Address is indicated below the Ethernet
interface. The actual temperature, and fan speed values are given in adjustable intervals. Programming
can be performed graphically via PC. Up to 30 chambers with RS 422 interface can be cross linked. For
further information, refer to the operating manual of the BINDER communication software APT-COM™ 3.
19.2 RS RS 422 interface (option)
With this option, the chamber is equipped with a serial interface RS 422 (4) instead of the Ethernet inter-
face, that can connect the BINDER communication software APT-COM™ 3 DataControlSystem. The
MAC Address is indicated below the Ethernet interface. The actual temperature, and fan speed values
are given in adjustable intervals. Programming can be performed graphically via PC. For further infor-
mation, refer to the operating manual of the BINDER communication software APT-COM™ 3.
The connection to a computer is established using the chamber interface via an interface converter.
Pin allocation of the RS 422 interface (4) on the
chamber rear
Pin 2: RxD (+)
Pin 3: TxD (+)
Pin 4: RxD (-)
Pin 5: TxD (-)
19.3 Data logger kit (option)
The BINDER Data Logger Kit offers an independent long-term measuring system for temperature, availa-
ble for different temperature ranges.
The BINDER Data Logger is equipped with a keyboard and a large LCD display, alarm functions and a
real-time function. Measurement data are recorded in the Data Logger and can be read out after the
measurement via the RS232 interface of the Data Logger. It offers a programmable measuring interval
and permits storing up to 64000 measuring values. Reading out is done with the Data Logger evaluation
software. You can give out a combined alarm and status protocol directly to a serial printer.
Data Logger Kit T 220: Measuring sensor for the temperature values of the chamber: Temperature
range -90 °C / 194 °F up to +220 °C / 428 °F.
For detailed information on installation and operation of the BINDER Data Logger, please
refer to the mounting instructions Art. No. 7001-0204 and to the original user manual of the
manufacturer, supplied with the data logger.
