KB (E4 + E6) 02/2017 page 22/148
With an increased amount of dust in the ambient air, clean the condenser fan (by suction or blowing) sev-
eral times a year.
Avoid any conductive dust in the ambiance according to the chamber layout complying with pollution de-
gree 2 (IEC 61010-1).
Do not install or operate the chamber in potentially explosive areas.
DANGER
Explosion hazard.
Danger of death.
∅ Do NOT operate the chamber in potentially explosive areas.
KEEP explosive dust or air-solvent mixtures AWAY from the vicinity of the chamber.
4. Installation of the equipment
4.1 Spacers for wall distance – KB 240 / 400 / 720 (E6)
Please fix both spacers with the supplied screws at the chamber rear. This serves to ensure the pre-
scribed minimum distance to the wall of 100 mm / 3.94 in.
Figure 9: Spacer for rear wall distance
Figure 10: Rear KB 240 / 400 / 720 (E6) with mounted spacers
