KB (E4 + E6) 02/2017 page 97/148
14.5.2 History – list of all alarms
To access the overview list of all alarms, go to Menu > Alarms > History
This list indicates the moment when an alarm was set and when cleared.
Fixed value
08.03.2015 15:05:06
Submenu “History” (example).
The list shows when the alarms of the current day
were triggered and when cleared. The most recent
message appears at the end of the list.
The information that an alarm has been acknowl-
edged is shown in the event list.
..\ History
08.03.2015 : Messages of indicated day
14:39:48
Alarm set Safety controller overtemperature
15:03:22
Alarm cleared Safety controller overtemperature
Close Home
When there is more information than one page, you can scroll the list in both directions with the operating
button.
To select a different date, select “Messages of indicated day” and press the operating button. You can
enter the desired date through an entry menu.
Fixed value
08.03.2015 05:05:06
Entry menu “Select date”.
The current date is shown. Enter the desired date
with the operating button.
Press the “Ok” button to confirm.
..\ Select date (DD.MM.YYYY)
0
8.03.2015
0
Ins Pos1 End Ok 1 2 3 4 5 6 7 8 9
Close Ok Home
The alarm list of the selected date is displayed.
The entire sequence of the alarm events (set – acknowledged – cleared) is shown in the event list (chap.
15).
To access the event list, go to Menu > Event list or User > View event list
Fixed value
08.03.2015 15:05:06
Submenu “Event list” (example).
The events and alarm messages of the current day
are displayed. The most recent message appears at
the end of the list.
..\ Event list
08.03.2015 : Messages of indicated day
14:17:20
Fan setpoint 50.00
14:35:12
Fan setpoint 100.00
14:39:48
Alarm set Safety controller overtemperature
14:40:19
Alarm acknowledged Safety controller overtempera-
ture
15:03:22
Alarm cleared Safety controller overtemperature
Close Home
