KB (E4 + E6) 02/2017 page 15/148
2.1 Chamber overview
Instrument panel with microprocessor
controller T4.12 and USB interface
Door handle
Chamber door
Refrigerating module
Main power switch (1)
Figure 4: Cooling incubator KB 53 / 115 (E4)
Instrument panel with microprocessor
controller T4.12 and USB interface
Door handle
Chamber door
Refrigerating module
Lateral control panel with main power
switch and connections
Figure 5: Cooling incubator KB 240 / 400 / 720 (E6)
