USER MANUAL
TD069-O&M-001
REVISION 6
Page 10 of 80
2 DESCRIPTION OF QUBE SYSTEM
2.1 Purpose of System
The Bioquell QUBE is an aseptic processing workstation with integrated HPV
decontamination system. This system can be used for various applications
including: sterility testing; pharmacy compounding, aseptic material transfer and
others that require an aseptic environment. It is a modular system that is
configurable to the Client’s needs.
The QUBE is loaded via the front access window. Dependent upon the application,
the QUBE may be supplied with Bioquell “SafeSort
1
”, internal racking and rails.
There is a Product Description Sheet for each of the optional accessories available
from Bioquell.
All replacement or serviceable parts are accessible from the front of the QUBE;
thereby allowing it to be positioned against a wall. Key access is required to
components that may present a hazard.
2.2 QUBE Modules
The QUBE system is modular incorporating a QUBE Hydrogen Peroxide Vapour
(QHPV) Module and additional modules dependent upon ordered configuration:
• QUBE Extension Module (QEXT) (max.2)
• QUBE Side Door Module (QSDM)
• QUBE Material Transfer Device (QMTD)
· QUBE Open Connection Module (QOCM)
· QUBE Closed Connection Module (QCCM)
· QUBE Rapid Transfer Port (QRTP)
· QUBE Blank Plate Module (QBPM)
As standard the QHPV Module is supplied without integrated continuous particle
monitoring or active air sampling systems (unless ordered as part of the
configuration). However, it is fitted with the connections for these systems
including having a “Dummy cone” in place.
Figure 1 depicts one typical configuration of a QUBE system. The QUBE is
available as a 1-chamber, 2-chamber or 3-chamber system of various
configurations.
1
Bioquell SafeSort is a prescription decontamination system designed for gassing components and
used in hospital pharmacy applications.
