USER MANUAL
TD069-O&M-001
REVISION 6
Page 71 of 80
9 SPECIFICATION
The following specification relates generally to the QUBE system.
Unit Dimensions
(WxHxD):
QHPV & QEXT
modules
QMTD module
Overall External 1360 x 2335 x 843 mm (53.5“ x 91.9“ x
33.2“)
Inside Chamber 1100 x 750 x 540 mm
(43.3“ x 29.5“ x 23.6“)
External 660 x 1750 x 800 mm (25.9 x 68.9 x 31.5”)
Usable space 440 x 495 x 365 mm (17.3 x 19.5 x 14.4”)
Unit Weight: QHPV
QEXT
QMTD
280 kg (617.3 lbs)
240 kg (529.1 lbs)
64 kg (141 lbs)
Air Quality: ISO 14644-1 Class 5 (EC GMP Annex 1 Grade
A; US Class 100)
Filtration: Chamber boundary 99.995% (EN 1822:2009 H14)
Inlet /Exhaust 99.95% (EN 1822:2009 H13)
Airflow System: Unidirectional
Downflow air
velocity:
At glove working height and
working zone
0.35m/s +/- 0.1
Exhaust airflow rate: 100-120 m
/hr (approx. 20%)
Chamber Pressure: User selectable between -60Pa to +75Pa
Chamber Lighting: Processing mode: Warm white. User adjustable from 0 to 1000
Lux at working surface
Bio-decontamination mode Blue
Decontamination
Method:
Hydrogen Peroxide Vapour Micro-condensation
Aeration Method: Integrated Catalyst
Cycle Time: ≈30 mins
(QHPV only)
H
2
0
2
Liquid Supply: · Bioquell Hydrogen Peroxide sterilant only
· 35% w/w (stored at 4°C to 25°C)
6
Materials of
Construction:
External surfaces: · Polypropylene (PP)
· Acrylonitrile Butadiene Styrene /
Polycarbonate Mix (ABS/PC)
· Clear cast acrylic
· Polyurethane (PU) Painted
· Aluminium Alloy (Epoxy coated)
· Stainless Steel
· Cast acrylic
· Polyester Labels
Internal chamber surfaces: · Polypropylene (PP)
· Acrylonitrile Butadiene Styrene /
Polycarbonate Mix (ABS/PC)
· Polyurethane (PU)
· Stainless Steel Flooring (316 grade)
· Polyester Labels
Door Sealing System: · Silicone inflatable seals with integrity
monitoring
4
Chamber shape may affect equipment location. For full chamber size & shape please contact
Bioquell
5
Dependent upon loading and absorbency of chamber contents. Time to decontaminate the complete
QUBE system depends upon load condition and configuration.
6
For a full Hydrogen Peroxide Specification please contact Bioquell or its agents
