USER MANUAL
TD069-O&M-001
REVISION 6
Page 12 of 80
2.2.4QUBE Material Transfer Device - QMTD
This module is positioned either on the left hand end, right hand end, or both
ends of the chambers. It can be used to transfer the load into and/or out of the
QUBE system.
2.2.5QUBE Open Connection Module – QOCM
The QOCM allows for a large open aperture between QEXT modules only, thus
making them into a 4-glove device.
2.2.6QUBE End Modules
The end panels for the QUBE system where a QMTD is not fitted can be one of the
following:
QUBE Closed Connection Module – QCCM
This is a solid end panel
QUBE Rapid Transfer Port – QRTP
This end panel has a 190mm diameter RTP fitted to it. There is a left and a right
hand version ensuring that the RTP always hinges to the back.
QUBE Blank Plate Module – QBPM
The end panel has a circular blank 3mm thick stainless steel sheet, through which
penetrations can be made to suit application.
