Bioquell QUBE - Page 13

USER MANUAL
TD069-O&M-001
REVISION 6
Page 13 of 80
Control Panel
Chamber test
point*
Processing
chamber
Stirrer
fans (2x)
Clear front
access window
H
2
O
2
Bottle
module
Key access to
components of
pneumatic
system
Figure 2: QHPV Module
Vaporiser outlet
Internal electrical
connections
Environmental
Monitoring
Module
Glove ports
(gloves and
sleeves not
shown)
Printer
Key access to
electrical system
Foot switch for
opening QSDMs
* Mating part is Bioquell part number H03020720 and has a 5/16” (8mm) Hose
barb outlet.
