USER MANUAL
TD069-O&M-001
REVISION 6
Page 72 of 80
Decontamination
Starting
Environmental
Limiting Conditions:
Temperature Limits: 16°C – 26°C (60.8°F – 78.8°F)
Relative Humidity Limits: 30 – 70% RH
Operating
Environmental
Conditions:
Temperature:
Relative Humidity:
5°C – 40°C
(41°F – 105°F)
80% Max
Control System: Embedded microprocessor control
Data Printer: Thermal print record
Internal Chamber
Connections (QHPV +
QEXT):
Electrical · (2x) Mini USB ‘B’ type
· (2x) AC Power (200W max)
· DC Power for Viable Monitor
Air · ISO-Cone for particle monitoring
External
Connections:
(items marked *
refer to QHPV only)
· Mains power supply input
· (2x) USB ‘A’ Type (connected to
chamber)
· Remote Room HPV Monitor
8
· Alarm status signal digital (volt-free)
output (requires voltage from external
equipment)
· Ethernet Data Output
· Viable monitor controller input (external
version)
· Pressure feedback from exhaust duct
(option)
Gas/Vapour · Low level HPV measurement point
· Glove/Sleeve leak test point (option)
Power
Requirements
9
:
230V AC: QHPV
QEXT
Single phase, 50/60 Hz (7.8 A max)
Single phase, 50/60 Hz (5 A max)
120V AC: QHPV
QEXT
Single phase, 50/60 Hz (15 A max)
Single phase, 50/60 Hz (7.8 A max)
100V AC: QHPV
QEXT
Single phase, 50/60 Hz (TBA A max)
Single phase, 50/60 Hz (TBA A max)
Power Supply: Installation category II
Power Consumption
QHPV Only:
Bio-
decontamination
mode:
QHPV
QEXT
1.8kW
1.15kW (230V), 0.94kW (120V)
Packaged
Dimensions:
(W x H x D)
Chamber: 1470 x 2050 x 1020 mm (57.8 x 80.7 x 40.1
inches)
Legs: 1420 x 920 x 970 mm (55.9 x 36.2 x 38.2
inches)
Packaged Gross
Weight:
409.5 kg (902.8 lbs)
Noise at 1m: Normal operation 54 dB(A)
7
System safe to operate but efficacy cannot be guaranteed.
8
HPV room monitoring equipment. Contact Bioquell for details.
9
Additional power will be required for additional modules. The current and power quoted are for 2
QMTDs fitted to a QHPV unit, a SteriTest pump, particle counter fitted and working and all internal
sockets fully loaded in the module.
