Modules
QHPV QMTD (Left)
QEXT QMTD (Right)
The outline colour of each module represents its condition; GREEN meaning
aseptic; AMBER not aseptic; BLUE when in cycle; RED during alarm conditions.
Administrative Functions
Back button
Print
currently
loaded cycle
recipe parameters
Confirmation Delete recipe
Save data Load cycle recipe
Administration
