CT-600-2 105
Address Signal
No.
Signal name Unit
%MW40124 - %MW40125 46 Status economizer suction bypass
%MW40126 - %MW40127 47 Status economizer oil return
%MW40128 - %MW40129 48 Switch economizer liquid level high
%MW40130 - %MW40131 49 Switch economizer oil level
... ... ... ...
%MW40152 - %MW40153 60 Compressor 1 suction pressure bara
%MW40154 - %MW40155 61 Compressor 1 discharge pressure bara
%MW40156 - %MW40157 62 Compressor 1 discharge temperature °C
%MW40158 - %MW40159 63 Compressor 1 discharge superheat °C
%MW40160 - %MW40161 64 Compressor 1 drive shaft frequency Hz
%MW40162 - %MW40163 65 Compressor 1 motor current A
%MW40164 - %MW40165 66 Compressor 1 actual CR position %
%MW40166 - %MW40167 67 Compressor 1 status oil valve
%MW40168 - %MW40169 68 Compressor 1 status economizer valve
%MW40170 - %MW40171 69 Compressor 1 status high pressure switch
%MW40172 - %MW40173 70 Compressor 1 status oil flow/level switch
%MW40174 - %MW40175 71 Compressor 1 status oil pressure switch
(OS85) / oil pressure (OS95)
-/bara
%MW40176 - %MW40177 72 Compressor 1 general alarm status
%MW40178 - %MW40179 73 Compressor 1 ready for operation status
%MW40180 - %MW40181 74 Compressor 1 capacity setpoint %
%MW40182 - %MW40183 75 Compressor 1 actual capacity %
%MW40184 - %MW40185 76 Compressor 1 running hours h
%MW40186 - %MW40187 77 Reserved (not used yet)
%MW40188 - %MW40189 78 Compressor 1 highest ranked alarm index
4
... ... ... ...
%MW40192 - %MW40193 80 Compressor 2 suction pressure bara
%MW40194 - %MW40195 81 Compressor 2 discharge pressure bara
%MW40196 - %MW40197 82 Compressor 2 discharge temperature °C
%MW40198 - %MW40199 83 Compressor 2 discharge superheat °C
%MW40200 - %MW40201 84 Compressor 2 drive shaft frequency Hz
%MW40202 - %MW40203 85 Compressor 2 motor current A
%MW40204 - %MW40205 86 Compressor 2 actual CR position %
%MW40206 - %MW40207 87 Compressor 2 status oil valve
4
See section 14.2 for reference to compressor specific alarm index numbers.
