Bitzer ACP Link - Page 107

CT-600-2 107
Address Signal
No.
Signal name Unit
%MW40272 - %MW40273 120 M172 - DI 1 - Emergency stop
%MW40274 - %MW40275 121 M172 - DI 2 - External alarm
%MW40276 - %MW40277 122 M172 - DI 3 - Start permission external
%MW40278 - %MW40279 123 M172 - DI 4 - Current limiter
%MW40280 - %MW40281 124 M172 - DI 5 - Run signal motor oil pump
%MW40282 - %MW40283 125 M172 - DI 6 - Thermo relay motor oil pump
%MW40284 - %MW40285 126 M172 - DI 7 - Remote eco enable
%MW40286 - %MW40287 127 M172 - DI 8 - PID Setpoint 2 enable
%MW40288 - %MW40289 128 M172 - DI 9 - not used
%MW40290 - %MW40291 129 M172 - DI 10 - Thermo relay/drive error motor 1
%MW40292 - %MW40293 130 M172 - DI 11 - Thermo relay/drive error motor 2
%MW40294 - %MW40295 131 M172 - DI 12 - Thermo relay/drive error motor 3
... ... ... ...
%MW40302 - %MW40303 135 M172 - AI 1 - Current motor 1 A
%MW40304 - %MW40305 136 M172 - AI 2 - Current motor 2 A
%MW40306 - %MW40307 137 M172 - AI 3 - Current motor 3 A
%MW40308 - %MW40309 138 M172 - AI 4 - External setpoint #2 %
%MW40310 - %MW40311 139 M172 - AI 5 - Suction temperature °C
%MW40312 - %MW40313 140 M172 - AI 6 - Discharge temperature °C
%MW40314 - %MW40315 141 M172 - AI 7 - Suction pressure bara
%MW40316 - %MW40317 142 M172 - AI 8 - Discharge pressure bara
%MW40318 - %MW40319 143 M172 - AI 9 - Process temperature °C
%MW40320 - %MW40321 144 M172 - AI 10 - Auxilary temperature °C
%MW40322 - %MW40323 145 M172 - AI 11 - External setpoint total and #1 %
%MW40324 - %MW40325 146 M172 - AI 12 - External setpoint #3 %
... ... ... ...
%MW40332 - %MW40333 150 M172 - DO 1 - Shutdown
%MW40334 - %MW40335 151 M172 - DO 2 - Common alarm
%MW40336 - %MW40337 152 M172 - DO 3 - Ready for operation signal
%MW40338 - %MW40339 153 M172- DO 4 - Run signal
%MW40340 - %MW40341 154 M172 - DO 5 - Start permission hp lp
%MW40342 - %MW40343 155 M172 - DO 6 - Start_request_chiller_pump
%MW40344 - %MW40345 156 M172 - DO 7 - not used
%MW40346 - %MW40347 157 M172 - DO 8 - Start signal oil pump
%MW40348 - %MW40349 158 M172 - DO 9 - Ecosys running
%MW40350 - %MW40351 159 M172 - DO 10 - not used
