Group ID Parametre Type Index Minimum Maximum Interpretation
Video
1.9 Recording format int16
[0] = file frame
rate
– –
fps as integer (eg 24, 25,
30, 50, 60, 120)
[1] = sensor frame
rate
– –
fps as integer, valid when
sensor-off-speed set (eg
24,25, 30, 33, 48, 50, 60,
120), no change will
beperformed if this value
is set to 0
[2] = frame width – – in pixels
[3] = frame height – – in pixels
[4] = flags
– – [0]=file-M-rate
– –
[1]=sensor-M-rate, valid
when sensor-off-speed-set
– – [2]=sensor-off-speed
– – [3]=interlaced
– – [4]=windowed mode
1.10 Set auto exposure mode int8 – 0 4
0=Manual Trigger, 1=Iris,
2=Shutter, 3=Iris + Shutter,
4=Shutter + Iris
Audio
2.0 Mic level fixed16 – 0 1
0.0=minimum,
1.0=maximum
2.1 Headphone level fixed16 – 0 1
0.0=minimum,
1.0=maximum
2.2 Headphone program mix fixed16 – 0 1
0.0=minimum,
1.0=maximum
2.3 Speaker level fixed16 – 0 1
0.0=minimum,
1.0=maximum
2.4 Input type int8 – 0 2
0=internal mic, 1=line level
input, 2=low mic level input,
3=high mic level input
2.5 Input levels fixed16
[0] ch0 0 1
0.0=minimum,
1.0=maximum
[1] ch1 0 1
0.0=minimum,
1.0=maximum
2.6 Phantom power boolean – – –
true = powered, false = not
powered
Output
3.0 Overlay enables
uint16 bit
field – – –
bit flags: [0] = display
status, [1] = display frame
guides
Some cameras don't allow
separate control of frame
guides and status overlays.
3.1
Frame guides style
(Camera 3.x)
int8
[0] = frame
guides style
0 8
0=off, 1=2.4:1, 2=2.39:1,
3=2.35:1, 4=1.85:1, 5=16:9,
6=14:9, 7=4:3
