Group ID Parametre Type Index Minimum Maximum Interpretation
Output
3.2
Frame guides opacity
(Camera 3.x)
fixed16
[1] = frame guide
opacity
0.1 1
0.0=transparent,
1.0=opaque
3.3
Overlays (replaces .1 and
.2 abovefrom Cameras
4.0) int8
[0] = frame
guides style
– –
0=off, 1=2.4:1, 2=2.39:1,
3=2.35:1, 4=1.85:1, 5=16:9,
6=14:9, 7=4:3
[1] = frame guide
opacity
0 100
0=transparent,
100=opaque
[2] = safe area
percentage
0 100
percentage of full frame
used by safe area guide (0
means off)
Display
4.0 Brightness fixed16 – 0 1
0.0=minimum,
1.0=maximum
4.1 Overlay enables
int16 bit
field
– – – 0x4 = zebra
– – – 0x8 = peaking
– – – –
4.2 Zebra level fixed16 – 0 1
0.0=minimum,
1.0=maximum
4.3 Peaking level fixed16 – 0 1
0.0=minimum,
1.0=maximum
4.4
Color bars display time
(seconds)
int8 – 0 30
0=disable bars,
1-30=enable bars with
timeout (s)
4.5 Focus Assist int8
[0] = focus assist
method
– –
0=Peak, 1=Colored lines
[1] = focus line
color
– –
0=Red, 1=Green, 2=Blue,
3=White, 4=Black
Tally
5.0 Tally brightness fixed16 – 0 1
Sets the tally front and tally
rear brightness to the same
level. 0.0=minimum,
1.0=maximum
5.1 Front tally brightness fixed16 – 0 1
Sets the tally front
brightness.0.0=minimum,
1.0=maximum
5.2 Rear tally brightness fixed16 – 0 1
Sets the tally rear
brightness.0.0=minimum,
1.0=maximumTally rear
brightness cannot be
turned off
Reference
6.0 Source int8 enum – 0 2
0=internal, 1=program,
2=external
6.1 Offset int32 – – – +/- offset in pixels
