Blackmagicdesign Studio User Manual

123
Developer Information
Group ID Parameter Type Index Minimum Maximum Interpretation
.1 Overlays int16 bit field 0x4 = zebra
0x8 = peaking
.2 Zebra level fixed16 0.0 1.0 0.0=minimum, 1.0=maximum
.3 Peaking level fixed16 0.0 1.0 0.0=minimum, 1.0=maximum
.4 Colour bars display time
(seconds)
int8 0 30 0=disable bars, 1-30=enable bars with timeout
(s)
Tally
5
.0 Tally brightness fixed16 0.0 1.0 Sets the tally front and tally rear brightness to
the same level. 0.0=minimum, 1.0=maximum
.1 Tally front brightness fixed16 0.0 1.0 Sets the tally front brightness. 0.0=minimum,
1.0=maximum
.2 Tally rear brightness fixed16 0.0 1.0 Sets the tally rear brightness. 0.0=minimum,
1.0=maximum
Tally rear brightness cannot be turned off
Reference
6
.0 Source int8 enum 0 1 0=internal, 1=program, 2=external
.1 Offset int32 +/- offset in pixels
Configuration
7
.0 Real Time Clock int32 [0] time BCD - HHMMSSFF
[1] date BCD - YYYYMMDD
.1 Reserved Reserved
Colour
Correction
8
.0 Lift Adjust fixed16 [0] red -2.0 2.0 default 0.0
[1] green -2.0 2.0 default 0.0
[2] blue -2.0 2.0 default 0.0

Blackmagicdesign Studio Specifications

General

Video Resolution	4K
Frame Rates	23.98, 24, 25, 29.97, 30 fps
Display Resolution	1920 x 1080
Video Outputs	HDMI, SDI
Audio Inputs	XLR, 3.5mm
Audio Outputs	3.5mm
Remote Control	Yes
Power Input	12V DC
Recording Media	CFast
