Blackmagicdesign Studio User Manual

4
Contents
Blackmagic Studio Camera
5 Getting Started
Attaching a Lens 5
Turning Your Camera On 5
6 Camera Features
Blackmagic Studio Camera Features 6
Blackmagic Micro Studio Camera 4K Features 8
10 Camera Connections
Blackmagic Studio Camera - Left Side 10
Blackmagic Studio Camera - Right Side 11
Blackmagic Micro Studio Camera 4K - Left Side 12
Blackmagic Micro Studio Camera 4K - Right Side 13
14 Customization
Blackmagic Micro Studio Camera 4K Expansion Cable 14
Wiring diagram for the Blackmagic Micro Studio
Camera Expansion Cable 15
16 Camera Settings
Camera Settings 16
Audio Settings 18
Monitoring Settings 20
Studio Settings 21
Remote Settings 22
Button Settings 22
24 Camera Video Output
Connecting to Video Switchers 24
Connecting to Recorders 24
25 Blackmagic Camera Setup
26 Attaching Accessories
Sun Shade 26
Other Accessories 26
27 Using ATEM Software Control
Introducing Camera Control 27
Using Camera Control 28
DaVinci Resolve Primary Color Corrector 30
Synchronizing Settings 32
33 Developer Information
Blackmagic Video Device Embedded Control Protocol 33
42 Help
43 Warranty

Blackmagicdesign Studio Specifications

General

Video Resolution	4K
Frame Rates	23.98, 24, 25, 29.97, 30 fps
Display Resolution	1920 x 1080
Video Outputs	HDMI, SDI
Audio Inputs	XLR, 3.5mm
Audio Outputs	3.5mm
Remote Control	Yes
Power Input	12V DC
Recording Media	CFast
