Blackmagicdesign Studio User Manual

164 Developer Information
Group ID Parameter Type Index Minimum Maximum Interpretation
.3 Reserved Reserved
.4 Reserved Reserved
.5 Exposure (us) int32 1 42000 time in us
.6 Exposure (ordinal) int16 0 n Steps through available exposure values from
minimum (0) to maximum (n)
.7 Dynamic Range Mode int8 enum 0 1 0 = film, 1 = video
.8 Video sharpening level int8 enum 0 3 0=Off, 1=Low, 2=Medium, 3=High
Audio
2
.0 Mic level fixed16 0.0 1.0 0.0=minimum, 1.0=maximum
.1 Headphone level fixed16 0.0 1.0 0.0=minimum, 1.0=maximum
.2 Headphone program mix fixed16 0.0 1.0 0.0=minimum, 1.0=maximum
.3 Speaker level fixed16 0.0 1.0 0.0=minimum, 1.0=maximum
.4 Input type int8 0 2 0=internal mic, 1=line level input, 2=low mic
level input, 3=high mic level input
.5 Input levels fixed16 [0] ch0 0.0 1.0 0.0=minimum, 1.0=maximum
[1] ch1 0.0 1.0 0.0=minimum, 1.0=maximum
.6 Phantom power boolean true = powered, false = not powered
Output
3
.0 Overlays uint16 bit field 0x1 = display status
0x2 = display guides
Some cameras don’t allow separate control of
guides and status overlays.
Display
4
.0 Brightness fixed16 0.0 1.0 0.0=minimum, 1.0=maximum

Blackmagicdesign Studio Specifications

General

Video Resolution	4K
Frame Rates	23.98, 24, 25, 29.97, 30 fps
Display Resolution	1920 x 1080
Video Outputs	HDMI, SDI
Audio Inputs	XLR, 3.5mm
Audio Outputs	3.5mm
Remote Control	Yes
Power Input	12V DC
Recording Media	CFast
