Blackmagicdesign Studio User Manual

329
D e veloper Information
Defined Commands
Command 0 : change configuration
Category (uint8)
The category number specifies one of up to 256 configuration categories
available on the device.
Parameter (uint8)
The parameter number specifies one of 256 potential configuration
parameters available on the device. Parameters 0 through 127 are device
specific parameters. Parameters 128 though 255 are reserved for parameters
that apply to multiple types of devices.
Data type (uint8)
The data type specifies the type of the remaining data. The packet length is
used to determine the number of elements in the message. Each message
must contain an integral number of data elements.
Currently defined values are:
0: void / boolean
A
void value is represented as a boolean array of length zero.
The
data field is a 8 bit value with 0 meaning false and all other values
meaning true.
1:
signed byte
Data
elements are signed bytes
2:
signed 16 bit integer
Data
elements are signed 16 bit values
3:
signed 32 bit integer
Data
elements are signed 32 bit values
4:
signed 64 bit integer
Data
elements are signed 64 bit values
5:
UTF-8 string
Data
elements represent a UTF-8 string with no terminating character.
Data
types 6 through 127 are reserved.

Blackmagicdesign Studio Specifications

General

Video Resolution	4K
Frame Rates	23.98, 24, 25, 29.97, 30 fps
Display Resolution	1920 x 1080
Video Outputs	HDMI, SDI
Audio Inputs	XLR, 3.5mm
Audio Outputs	3.5mm
Remote Control	Yes
Power Input	12V DC
Recording Media	CFast
