Bomar Individual Automatic Series User Manual

27
Dokumentace stroje Dokumentation der Maschinen Machine documentation
2.10.4. Tables for teeth selection
SHAPED MATERIAL (D
p
, S = mm)
Dp
S
D
p
S
S
D
p
Dp
S
Dp
S
Note: Table shows tooth system selection for cutting one piece of the profile. For cutting of more pieces of the profiles (bundle), you must think of the
size of the wall as double size of the wall of one profile (that means, size „S“ equates to 2×S). In table, there are tooth systems constant and variable.
Size of the
wall
S [mm]
Tooth system (Z
p
Z)
Outer diameter of the profile D
p
[mm]
20 40 60 80 100 120
2 32 S 24 S 18 S 18 S 14 S 14 S
3 24 S 18 S 14 S 14 S 10–14 S 10–14 S
4 24 S 14 S 10–14 S 10–14 S 8–12 S 8–12 S
5 18 S 10–14 S 10–14 S 8–12 S 6–10 S 6–10 S
6 18 S 10–14 S 8–12 S 8–12 S 6–10 S 6–10 S
8 14 S 8–12 S 6–10 S 6–10 S 5–8 S 5–8 S
10 - 6–10 S 6–10 S 5–8 S 5–8 S 5–8 S
12 - 6–10 S 5–8 S 5–8 S 4–6 K 4–6 K
15 - 5–8 S 5–8 S 4–6 K 4–6 K 4–6 K
20 - - 4–6 K 4–6 K 4–6 K 3–4 K
30 - - - 3–4 K 3–4 K 3–4 K
50 - - - - - 3–4 K
Size of the
wall
S [mm]
Tooth system (Z
p
Z)
Outer diameter of the profile D
p
[mm]
150 200 300 500 750 1000
2 10–14 S 10–14 S 8–12 S 6–10 S 5–8 S 5–8 S
3 8–12 S 8–12 S 6–10 S 5–8 S 4–6 K 4–6 K
4 6–10 S 6–10 S 5–8 S 4–6 K 4–6 K 4–6 K
5 6–10 S 5–8 S 4–6 K 4–6 K 4–6 K 3–4 K
6 5–8 S 5–8 S 4–6 K 4–6 K 3–4 K 3–4 K
8 5–8 S 4–6 K 4–6 K 3–4 K 3–4 K 3–4 K
10 4–6 K 4–6 K 4–6 K 3–4 K 3–4 K 2–3 K
12 4–6 K 4–6 K 3–4 K 3–4 K 2–3 K 2–3 K
15 4–6 K 3–4 K 3–4 K 2–3 K 2–3 K 2–3 K
20 3–4 K 3–4 K 2–3 K 2–3 K 2–3 K 2–3 K
30 3–4 K 2–3 K 2–3 K 2–3 K 1,4–2 K 1,4–2 K
50 2–3 K 2–3 K 2–3 K 1,4–2 K 1,4–2 K 1,4–2 K
75 - 2–3 K 1,4–2 K 1,4–2 K 1,4–2 K 0,75–1,25 K
100 - - 1,4–2 K 0,75–1,25 K 0,75–1,25 K 0,75–1,25 K
150 - - - 0,75–1,25 K 0,75–1,25 K 0,75–1,25 K
200 - - - 0,75–1,25 K 0,75–1,25 K 0,75–1,25 K
SOLID MATERIAL (D = mm)
D
D
D
D
D
Constant tooth system Variable tooth system
length of the cut D tooth system (Z
p
Z) length of the cut D tooth system (Z
p
Z)
to 3 mm 32 to 30 mm 10 –14
to 6 mm 24 20–50 mm 8–12
to 10 mm 18 25–60 mm 6–10
to 15 mm 14 35–80 mm 5–8
15–30 mm 10 50–100 mm 4–6
30–50 mm 8 70–120 mm 4–5
50–80 mm 6 80–150 mm 3–4
80–120 mm 4 120–350 mm 2–3
120–200 mm 3 250–600 mm 1,4–2
200–400 mm 2 500–3000 mm 0,75–1,25
300–800 mm 1,25
700–3000 mm 0,75
