59
Údržba stroje
Wartung
Machine maintenanceseZávady
4. Release all 3 screws (see arrow).
5. Release center M10 screw after remove retaining ring. Remove hardmetal holder
and bearing from bottom
6. Insert the pivot to the vice.
7. Remove the bearing pivot from the bearing holder by means of the swager.
8. Remove the worn bearing.
Attention:
The vice has aluminium jaws, eventually, there has to be an
aluminium agent to protect the pivot from damage.
