Probus DP V1 Agile 4706/2010
Handling of the Objects
Quick Stop
X
X
0
1
X
7, 10, 11
Disable Operation
X
0
1
1
1
5
Enable Operation X 1 1 1 1 4
Reset Fault
0
1
x x x x 15
"X" means any value.
Note:
State transition 3 (command "Switch On") is only processed if Bit 4 "Voltage en
abled" of the Status
Word is set.
State transition 4 is only processed if Bit 4 "Voltage enabled" of the Status Word is set.
Handling of the Objects
The Status Word displays the current operation state.
Status Word
State
Bit 6 Bit 5 Bit 3 Bit 2 Bit 1 Bit 0
Switch On
disabled
Quick
Stop
Fault Operation
enabled
Switched
On
Ready to
Switch On
Switch On disabled 1 X 0 0 0 0
Ready to Switch On 0 1 0 0 0 1
Switched On 0 1 0 0 1 1
Operation enabled 0 1 0 1 1 1
Quick Stop active 0 0 0 1 1 1
Fault Reaction active 0 X 1 1 1 1
Fault 0 X 1 0 0 0
"X" means any value.
Bit 7 "Warning" can be set at any time. It indicates a device-internal warning message.
The evaluation of the warning reason is carried out by reading out the warning status with Pa
rameter
Warnings
270.
Bit 9 "Remote" is set if the operation mode "control via state machine" (
Local/Remote
412
= 1) has
been set and the hardware release is available.
Logic linking of the digital control signals:
(STOA AND STOB) AND (Start clockwise OR Start anticlockwise)
The frequency inverter can only be controlled if the logic linking is true.
The logic inputs for Start
clockwise and Start anticlockwise can be connected directly to "ON" or "OFF" (Parameter Start-
clockwise
68 and
Start-anticlockwise
69).
Bit 10 "Target reached" is set whenever the specified reference value has been reached.
In the special case of power failure regulation, the bit is also set if the power failure regulation has
reached the frequency 0 Hz (see operating instructions).
For "Target reached" there is a hysteresis (tolerance range), which can be set via parameter
Reference
Value Reached: Hysteresis 549 (see operating instructions).
Bit 11 "Internal limit active" indicates that an internal limit is acti
ve. This can, for example, be the
present current limit, the torque limit or the over-
voltage limit. All of these limit functions lead to the
reference value being quit or not reached.
Bit 15 "Warning 2" indicates a warning which leads to a fault switch-off of the fre
quency inverter
within a short period of time. This bit is set if there is a warning for motor temperature, heat
sink/inside temperature, Ixt monitoring or mains phase failure.
