BIS 2.3 - Access Engine MAC - Main Access Controller | en 113
Bosch Sicherheitssysteme GmbH Installation manual F.01U.028.713 | V 2.3.0.1 | 2009.11
11.4 Process Control
The preceding sections have touched already on this
application, and described some of its functions. This section
will summarize the application in order to provide more clarity,
even at the cost of some repetition.
Right click on the MAC systray icon and select ProcessControl.
The ProcessControl dialog is displayed
Figure 11.1 MAC - Invoking Process control
Figure 11.2 MAC - Process Control
The Control field offers the following functions:
NOTICE!
Depending on the amount of data, but particularly if there are
many personnel and badge data, loading the database can take
some hours. During this period those access control functions
which are exclusively MAC-based (e.g. access tracking) will not
be available.
