BIS 2.3 - Access Engine Connecting readers and doors | en 71
Bosch Sicherheitssysteme GmbH Installation manual F.01U.028.713 | V 2.3.0.1 | 2009.11
1. Controller
–Name, description
–Interface type
– Set connection parameter
2. Reader
– Designation for the reader interface
–Reader name
– Entrance to which the reader belongs
3. Signals
–Signal number
– Entrance for which the signal was configured
– Sorting after input and output signals
– Signal designation
– Interfaces and used contacts of this interface
AMC_4W Data sheet
Device information:
Name: AMC 4-W-3
Description: AMC
Interface type: COM
Local port: 0
Bus number: 3
Remote port: 10001
Program: LCMV3702.RUN
Reader:
Connecto
r
Reader Entrance
S5 Reader-P 1 IN Parking-1 IN
S9 Reader-P 1 OUT Parking-1 OUT
S13
S17
Signals:
Si
g
nal Entrance Exit signal Entrance Input signal
0 0 Parking-1 IN Contact restoral
(S3; 1,2,3)
Parking-1 IN Door Contact
(S4; 1,2)
0 1 Parking-1 IN Door is permanent open
(S2; 1,2,3)
Parking-1 IN Door strike
(S4; 3,4)
0 2 Parking-1 IN Stoplight green
(S7; 1,2,3)
Parking-1 IN Passage locked
(S8; 1,2)
0 3 Parking-1 IN Alarm suppression
(S6; 1,2,3)
Parking-1 IN Passage completed
(S8; 3,4)
0 4 Parking-1 OUT Contact restoral
(S11; 1,2,3)
Parking-1 OUT Door Contact
(S12; 1,2)
0 5 Parking-1 OUT Door is permanent open
(S10; 1,2,3)
Parking-1 OUT Door strike
(S12; 3,4)
0 6 Parking-1 OUT Stoplight green Parking-1 OUT Passage locked
