6 Communication Channels
CAN bus
The C 80 has two CAN buses configurable as input and output. Different baud rates are
selectable. Please note that the C 80 does not contain any CAN termination resistors. Thus
the CAN termination resistors need to be integrated into the wiring loom.
Ethernet channels
The C 80 has three 100 MBit full duplex Ethernet communication ports. The ports are in-
ternally connected with an Ethernet switch. The Ethernet ports have 'cable auto crossover'
functionality.
RS232 ports
The C 80 has two RS232 serial ports. Baud rate for both ports is programmable. RS232
port 1 is reserved for online telemetry, port 2 can be used for reception of data from a
serial GPS receiver.
Vehicle diagnosis connector
The Bosch Motorsport vehicle diagnosis connector is used as a standard interface to con-
nect the vehicle to a PC e.g. via a MSA-Box II. Loom connector: AS012-35SN
Pin Name Description Used for C 80
Pin 1 Terminal 30 Permanent positive +
Pin 2 Terminal 15 Switched positive +
Pin 3 Terminal 31 GND +
Pin 4 CAN High Diagnostic CAN bus
Pin 16 CAN Low Diagnostic CAN bus
Pin 10 K-Line ECU diagnosis
Pin 8 Ethernet RxD + Ethernet interface +
Pin 9 Ethernet RxD - Ethernet interface +
Pin 11 Ethernet TxD + Ethernet interface +
Pin 12 Ethernet TxD - Ethernet interface +
Pin 22 Screen Cable screen +

Bosch C 80 Specifications

General

Resolution	16 bit
Interfaces	USB
Measurement Range	±10V
Accuracy	±0.1 % FS
Channels	8 universal analog inputs (±10 V, ±20 mA, Pt100, Pt1000, Thermocouples type K, S, J, T, N, R, B, E), 4 digital inputs (trigger, counter, frequency), 2 digital outputs (24 V / 500 mA)
