Technical Data | 4
Bosch Motorsport Manual_C_80 7/144
4 Technical Data
We offer the C 80 in two basic versions, on the one hand as a data logger and on the
other hand as a sensor interface. Choose between these basic variants and combine or
add functionalities now or later.
The data logger C 80 is a professional data logging system for motorsport applications.
This allows for synchronized acquisition of engine data from the ECU and chassis data
from up to 26 analog and 4 digital input channels. Additional input devices can be con-
nected via Ethernet and CAN buses.
Recorded data from the up to 16 GB logger can be downloaded via high speed Ethernet.
Software upgrades for the C 80 (field upgradable by entering a key) activate tailored con-
figurations like a second logging partition of 4 GB, USB recording, CCP/XCP-master for
simple data access to third party devices, as well as additional input channels.
Converters 10 kHz 12 bit AD converters with digital
low pass filter
Configurable math channels
User configurable CAN in/out messages
Sampling rate
Online data compression
Internal logger
– 4GB memory on partition 1 (optional; included in C 80 Logger)
– Plus 16 GB memory on partition 1 (optional)
– Plus 4 GB memory on partition 2 (optional)
– Up to 1,500 channels
– Fastest sampling 1,000 Hz for all channels
Logging rates
– Usage of all features: 800 kB/s
– Primary logging use case: >1,500 kB/s
– Logging data download rate: up to 7.5 MB/s
3-port network switch
Telemetry Support via Ethernet (recommended) and RS232
Mechanical Data
Size 105 x 34.5 x 137.5 mm
Weight 462 g
Protection Classification IP67 to DIN 40050, Section 9, Issue 2008
Max. vibration Vibration profile 1 (see Appendix or
www.bosch-motorsport.com)
Operating temperature (internal) 0 to 85°C
Operation outside the temperature limits can be tested on request during the manufac-
turing tests.
Electrical Data
Supply voltage 8 to 18 V
