14 Recording
14.1 Features
– Synchronized recording of C 80 analog and digital input channels, C 80 internal meas-
urement channels, ECU data, Data from external sensor interfaces
– Up to two independent recordings
– Measurement rate 1 ms to 1 s
– Two global start conditions (thresholds)
– Up to 16 measurement conditions (fast-slow-switches)
14.2 Configuration of Recordings
1. Expand the ‘Logger’ list by clicking on ‘+’ in the C 80 Project Tree.
2. Double-click on ‘Logging’ in the C 80 Project Tree.
The recording configuration is displayed in the Main Area.
Click on '+'
Double-click on
'Logging'
Alternatively, click on the ‘Logger’ tab to open the configuration directly.
