16.3 Analog Input Diagnosis
16.3.1 Monitoring limits / Shortcut Detection / Cable
Breakage
The pin diagnosis functionality (check whether measurement is within the desired range)
can be activated in the ANA pin setup wizard; to allow for a diagnosis regarding shortcut
to ground, shortcut to battery voltage and cable breakage, a minimum / maximum has to
be defined.
