GPS Sensor | 20
Bosch Motorsport Manual_C_80 129/144
20 GPS Sensor
20.1 GPS (Global Positioning System)
Space-based global navigation satellite system.
GPS provides positioning, navigation, and timing services to worldwide users.
GPS receiver (sensor) gives digital information about position (longitude, latitude, height),
ground speed, course, and status.
Two types of GPS receivers:
CAN output -> Read in messages via CAN Input of C 80 (not covered here)
Serial output -> Read in messages via RS232 Interface of C 80
Serial Interface is characterized by:
Voltage levels: RS232 is standard (+/-12 V), UART (0 V/ 5 V) needs level shifter
Baud rate: 9,600 is standard for GPS, C 80 supports 1,200 to 115,200 baud. GPS Rx inter-
face baud rate must match C 80 interface baud rate. C 80 Baud rate can be set with the
‘GPS_BAUDRATE’ characteristic Data format: C 80 expects 8 data bits, no parity bit, 1 stop
bit (8N1)
20.1.1 Serial interface characterization
Serial Interface is characterized by:
Voltage levels: RS232 is standard (+/-12 V), UART (0 V/ 5 V) needs level shifter
Baud rate: 9,600 is standard for GPS, C 80 supports 1,200 to 115,200 baud. GPS Rx inter-
face baud rate must match C 80 interface baud rate. C 80 Baud rate can be set with the
‘GPS_BAUDRATE’ characteristic Data format: C 80 expects 8 data bits, no parity bit, 1 stop
bit (8N1)
20.2 Protocol
C 80 expects NMEA Protocol (ASCII).
The following messages are decoded:
Message Function
GGA GPS fix information
GSA Overall satellite data
GSV Detailed satellite data
RMC Recommended minimum data for GPS
VTG Vector track and speed over the ground
On most GPS sensors, these messages are activated in the default configuration.
