9 | Project Configuration
38/144 Manual_C_80 Bosch Motorsport
9.5 Display Switch Module
You can use the Display Switch Module to switch display pages and brightness. The out-
put is a display page or brightness output that can be used in display configurations. The
value sustains over a power cycle.
The conditions for incrementing/decrementing the value can be set freely. The maximum
value can be set as constant or read from a measurement.
The page can be configured to wrap around. In this case, no page down condition is
needed.
The resulting outputs are the display switch value and the input conditions.
Measurement label Function
name page or brightness value
name_dn input condition for decrement
name_up input condition for increment
Example:
