4 | Technical Data
8/144 Manual_C_80 Bosch Motorsport
Max. power consumption (w/o loads) 10 W at 14 V
Inputs
Analog channels 6
Input range 0 to 5 V
Resolution 12 bit
Switchable pull up resistor 3 kOhm
Outputs
PWM outputs (low side switch 2Aeach) 4
Sensor supply 5 V ± 1 % (250mA) 1
Connectors and Wires
Motorsport connectors double density 2 x 41 pins
Mating connector I
ASDD612-41SN
F02U.002.216-01
Mating connector II
ASDD612-41SA
F02U.004.180-01
Pin Layout ASDD212-41PN
Pin Name Description
1 KL30
2; 3 KL15
4; 5 KL31
6 Ethernet Channel0 Tx plus Wire Ethernet_0 - TX+
7 Ethernet Channel0 Tx minus Wire Ethernet_0 - TX-
8 Ethernet Channel0 Rx plus Wire Ethernet_0 - RX+
9 Ethernet Channel0 Rx minus Wire Ethernet_0 - RX-
10 Ethernet Schirm Ethernet Schirm
11 Ethernet Channel1 Tx plus Wire Ethernet_0 - TX+
12 Ethernet Channel1 Tx minus Wire Ethernet_0 - TX-
13 Ethernet Channel1 Rx plus Wire Ethernet_0 - RX+
14 Ethernet Channel1 Rx minus Wire Ethernet_0 - RX-
15 Ethernet Channel2 Tx plus Wire Ethernet_0 - TX+
16 Ethernet Channel2 Tx minus Wire Ethernet_0 - TX-
17 Ethernet Channel2 Rx plus Wire Ethernet_0 - RX+
18 Ethernet Channel2 Rx minus Wire Ethernet_0 - RX-
19 CAN_A_H CAN_A - HIGH
20 CAN_A_L CAN_A - LOW
21 CAN_B_H CAN_B - HIGH
22 CAN_B_L CAN_B - LOW
23 USB Power 500mA USB_Power
24 USB Data Plus USB_OTG_Plus

Bosch C 80 Specifications

General

Resolution	16 bit
Interfaces	USB
Measurement Range	±10V
Accuracy	±0.1 % FS
Channels	8 universal analog inputs (±10 V, ±20 mA, Pt100, Pt1000, Thermocouples type K, S, J, T, N, R, B, E), 4 digital inputs (trigger, counter, frequency), 2 digital outputs (24 V / 500 mA)
