3 Playback
mode
and
channel
selection
pane
Choose between 1/4/9/16 window or full screen (toggle the buttons during
playback to switch between views):
– 1-window – select which channel to display from the drop-down menu
(select ‘..’ for no channel)
– 4-window (select which 4 channels to display)
– 9-window (select channels 1 to 9)
– 16-window (switch between1-16 and 17-32 channels – only available
for DIVAR AN 5000 )
– Full-screen (click right mouse button to exit full screen)
4 Calendar
and time
Select a date to overview the recordings available for that day (dates
highlighted in blue have recordings available for that day). The time bar on
the bottom of the screen will show a 24-hour trace of the recordings
available for the chosen date.
If required, play a recording for a particular date as follows:
– Assign a start time (hour, minute, second) in the time field (below the
calendar)
– Press the play button
– Click on a colored zone on the time bar (at the bottom of the screen)
to start playing at that selected time
– Note: Select ‘Time display’ and/or ‘Channel display’ to show this
information as an overlay in the chosen recording.
DIVAR 2000 / DIVAR 3000 / DIVAR
5000
Operation | en 61
Bosch Security Systems Operation Manual 2016.09 | v1.0 | AM18-Q0717
