Bosch DIVAR 3000 User Manual

6 Play or Pause (the ‘pause’ button is displayed if the DVR is already playing
and you wish to pause the play)
Stop playback
Backward play
In normal play mode, left click this button to play the file backwards. Click it
again to pause current play.
In backward play mode, click to restore normal play.
In playback mode, click to play the next or the previous section (click
continuously to watch consecutive files from the same channel).
In normal play mode, press pause then click and to begin frame-by-
frame playback.
In frame-by-frame playback mode, click
to restore normal playback.
Slow play
In playback mode, click for various slow play modes such as slow play 1,
slow play 2, etc.
Fast forward
In playback mode, click to realize various fast play modes such as fast
play 1, fast play 2, etc.
Smart search (only available for analog cameras connected to a hybrid
recorder) – see description below
Turn the audio on/off and adjust the volume during video playback
Click to export snapshot(s) to a USB memory device, a DVD, and/or an
email address.
– A disclaimer screen may initially appear when you first select Snapshot
(click <Accept> to continue).
See heading ‘Export snapshot’ for more information.
Digital
zoom
When the system is in playback mode:
1. Left-click the mouse in the screen and hold down the mouse button.
2. Drag to select a section then release the mouse button.
3. Left-click in the selection for digital zoom of the selection.
4. Right-click to exit zoom.
DIVAR 2000 / DIVAR 3000 / DIVAR
5000
Operation | en 63
Bosch Security Systems Operation Manual 2016.09 | v1.0 | AM18-Q0717

Bosch DIVAR 3000 Specifications

General

AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	20 W
Storage temperature (T-T)	0 - 93 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	0 - 95 %
Operating relative humidity (H-H)	-40 - 70 %
Sustainability certificates	RoHS
Certification	EMC, LVD, UL, cUL, CAN/CSA, BIS, RCM, ACMA EMC, CE, FCC
On/off switch	Yes
Product color	Black, Silver
Rack capacity	-
Bit rate	24000 Kbit/s
Display modes	Live view
Playback modes	Fast play, Forward, Frame by Frame, Reverse, Slow play
Input bandwidth	320 Mbit/s
Number of users	128 user(s)
Recording modes	Manual, Schedule, Stop
Output bandwidth	256 Mbit/s
Maximum resolution	3840 x 2160 pixels
Alarm input channels	16
Video input channels	16 channels
Alarm output channels	3
Supported resolutions	3840×2160, 1920×1080, 1280×1024, 1280×720, 1024×768, 970x576, 704x576, 352x576, 352x288, 176x144, 960x480, 704x480, 352x480, 352x240, 176x120
Video recording modes	720p, 1080p
Video formats supported	H.264, H.265, M-JPEG
RS-232 ports	1
Audio RCA inputs	4
Networking standards	IEEE 802.3
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN (RJ-45) ports	2
Supported network protocols	HTTP, HTTPS, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS/DDNS, IP Filter, PPPoE, FTP
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Wi-Fi	No
HDD capacity	- GB
HDD interface	Serial ATA
Maximum storage capacity	6 TB
Mobile operating systems supported	Android, iOS

Weight and Dimensions

Depth	323 mm
Width	375 mm
Height	53 mm
Weight	4130 g
