Carriers and channels
The Integrus system can transmit up to 8 different carrier signals (depending on the
transmitter type). Each carrier can contain up to 4 different audio channels. The maximum
number of channels per carrier is dependent on the selected quality modes. Stereo signals use
twice as much bandwidth as a mono signals; premium quality uses twice as much bandwidth
as standard quality.
Per carrier a mix of channels with different quality modes is possible, as long as the total
available bandwidth is not exceeded. The table below lists all possible channel combinations
per carrier:
Channel quality
Mono
Standard
Mono
Premium
Stereo
Standard
Stereo
Premium
Bandwidth
Possible
number
of
channels
per
carrier
4 4 x 10 kHz
2 1 2 x 10 kHz and 1 x 20 kHz
2 1 2 x 10 kHz and 1 x 10 kHz (left)
and
1 x 10 kHz (right)
1 1 1 x 20 kHz and 1 x 10 kHz (left)
and
1 x 10 kHz (right)
2 2 x 10 kHz (left) and 2 x 10 kHz
(right)
2 2 x 20 kHz
1 1 x 20 kHz (left) and 1 x 20 kHz
(right)
4.1.4
