Installation
Integrus Transmitters
The transmitter is suitable for either table-top or 19-inch rack-mounted use. Four feet (for
table top use) and two mounting brackets (for rack mounting) are supplied. The mounting
brackets can also be used to mount the transmitter to a flat surface.
Figure 5.1: Transmitter with optional mounting brackets and table-top feet
Audio input and Interpreter module
1
2
Figure 5.2: Module slot cover
5
5.1
5.2
