Bosch INTEGRUS - Set Transmission (4 A); Set Network Mode (4 B)

Menu Item Description
Transmitter Status Shows the transmitter status (see section View transmitter
status, page 69)
1 Fault Status Shows the radiator fault status (see section Fault messages, page
72)
2 Monitoring . . . Go to the ‘Monitoring’ sub-menu (see section Integrus
Transmitter, page 66)
3 Enquiry . . . Go to the ‘Enquiry’ sub-menu (see section Service requests, page
75)
4 Setup . . . Go to the ‘Setup’ sub-menu (see sections Set transmission (4A),
page 52 and higher)
Set transmission (4A)
The Transmission menu item (4A) is used to select which signals will be distributed over the
channels. It is also possible to switch all channels off (Standby). When using an Integrus
system with a DCN Next Generation system (see section Set network mode (4B), page 52),
the transmitter is automatically switched to 'Standby' when the connected DCN Next
Generation system is switched off. When the DCN Next Generation system is switched on, the
transmitter is automatically switched to 'On'.
Menu Item Options Description
4A Transmission Mode:
- Standby All channels are switched off, no signals are
distributed.
* - On Normal transmission. Input signals are
distributed on the channels as set in the
Channel Quality sub-menu (4D).
- Aux to All The signals on the Auxiliary inputs are
distributed on one carrier to all channels.
- Test A different test tone is distributed on each
channel. The frequency increases with
increasing channel number. For stereo
channels the tone for left and right will also
be different.
- Slave The radiator signal on the slave input is
looped-through to all radiators.
Set network mode (4B)
The Network Mode menu item (4B) is used to enable the optical network connections. When
the transmitter is connected to a DCN Next Generation conference system, the optical
network connections must be enabled.
7.2.2
7.2.3
52 en | Configuration Language Distribution System
2013.11 | V1.4 | Operation manual Bosch Security Systems B.V.
