Mechanical Data
Transmitters and Modules
Infra Red Transmitters
Dimensions (H x W x D)
for tabletop use, with feet 92 x 440 x 410 mm
(3.6 x 17.3 x 16.1 in)
for 19” rack use, with brackets 88 x 483 x 410 mm
(3.5 x 19 x 16.1 in)
in front of brackets 40 mm (1.6 in)
behind brackets 370 mm (14.6 in)
Weight
without brackets, with feet 6.8 kg (15.0 lb)
Mounting Brackets for 19” rack mounting or fixing to a
tabletop
Detachable feet for free-standing on a tabletop
Color Charcoal (PH 10736) with silver
Integrus audio input and interpreters module
Mounting
Front panel is removed when used with INT‑TX
Integrus Transmitter
Dimensions (H x W x D)
without front panel 100 x 26 x 231 mm (39 x 10 x 91 in)
Weight
without front panel 132 g (0.29 lb)
Radiators and Accessories
Radiators and Accessories
Mounting – Suspension bracket for direct ceiling
mounting.
– Mounting plates for floor stands with M10
and 1/2 in Whitworth thread.
– Optional wall mounting bracket
(LBB 3414/00) available.
– Safety eye.
Dimensions (H x W x D)
LBB 4511 without bracket 200 x 500 x 175 mm
(7.9 x 19.7 x 6.9 in)
LBB 4512 without bracket 300 x 500 x 175 mm
(11.0 x 19.7 x 6.9 in)
Radiator angle
12.2
12.2.1
12.2.2
