Menu Item Options Value Description
-6 ... +6 dB Set the required sensitivity for the right
auxiliary input.
4L Level Inputs Mode: Level:
- All -6 ... +6 dB Set the sensitivity of all audio inputs to a user
defined level.
- Per Input ... Select this option to go to the ‘Per Input
Sensitivity Settings’ menu.
The sensitivity screens also displays a level meter for a visual indication of the actual signal
strength: = low level, = high level, = overflow.
Enable / disable IR-monitoring (4M)
The mini IR-radiator at the front of the transmitter can be used for monitoring the IR-signal.
When required (e.g. for security reasons) this option can be switched off (menu 4M).
Menu Item Options Description
4M Mini Radiator Enabled Enable the mini IR-radiator at the front of the
transmitter.
Disabled Disable the mini IR-radiator at the front of the
transmitter.
Notice!
The mini IR-radiator and the headphone output can also be permanently disabled by removing
two resistors. Consult your regular service contact for more information.
Enable / disable headphone output (4N)
The headphone output at the front of the transmitter can be used for monitoring the input-and
channel signals. When required (e.g. for security reasons) this option can be switched off in
menu item 4N.
Menu Item Options Description
4N Headphone Enabled Enable the headphone output at the front of
the transmitter.
Disabled Disable the headphone output at the front of
the transmitter.
Choose transmitter name (4O)
The transmitter can be assigned a user-defined name. This name is used in the Transmitter
Status screen. The name can be edited in the Unit Name menu (4O).
Menu Item Options Description
4O Unit Name Name:
- Free text Assign a user defined name to the transmitter
(max. 16 characters). The default name is
‘Transmitter’.
7.2.12
7.2.13
7.2.14
58 en | Configuration Language Distribution System
2013.11 | V1.4 | Operation manual Bosch Security Systems B.V.
