Bosch INTEGRUS - Table of Contents

Table of contents
1
Safety 6
2
About this manual 7
2.1 Purpose 7
2.2 Intended audience 7
2.3 Related documentation 7
2.4 Alerts and notice signs 7
2.5 Copyright and disclaimer 7
2.6 Document history 8
3
System Overview 9
3.1 System Overview 9
3.2 Integrus Transmitters 11
3.3 Audio input and Interpreter module 13
3.4 Integrus Radiators 14
3.5 Integrus Receivers 17
3.6 Receiver Headphones 18
3.7 Integrus Charging Units 19
4
Planning 20
4.1 System technology 20
4.1.1 IR radiation 20
4.1.2 Signal Processing 21
4.1.3 Quality modes 21
4.1.4 Carriers and channels 22
4.2 Aspects of Infrared distribution systems 23
4.2.1 Directional sensitivity of the receiver 23
4.2.2 The footprint of the radiator 23
4.2.3 Ambient lighting 25
4.2.4 Objects, surfaces and reflections 26
4.2.5 Position the radiators 26
4.2.6 Overlapping footprints and black spots 29
4.3 Plan an Integrus infrared radiation system 30
4.3.1 Rectangular footprints 30
4.3.2 Plan radiators 31
4.3.3 Cabling 32
5
Installation 33
5.1 Integrus Transmitters 33
5.2 Audio input and Interpreter module 33
5.3 Medium and High Power Radiators 35
5.3.1 Attach mounting plate to the suspension bracket 36
5.3.2 Attach the suspension bracket 37
5.3.3 Mount radiator on a floor stand 37
5.3.4 Mount radiator on a wall 38
5.3.5 Mount radiator on a ceiling 40
5.3.6 Mount radiator on horizontal surfaces 40
5.3.7 Secure the radiator with safety cord. 40
5.4 Integrus receivers 40
5.5 Integrus Charging Units 41
Language Distribution System Table of Contents | en 3
Bosch Security Systems B.V. Operation manual 2013.11 | V1.4 |
