LBB 4511/00 at full power LBB 4512/00 at full power
Nr. H a A L W X A L W X
30 165 15 11 3,5 294 21 14 4
45 120 12 10 1,5 195 15 13 1,5
60 90 10 9 -0,5 156 13 12 -1
90 81 9 9 -4,5 121 11 11 -5,5
10 45 154 14 11 3 285 19 15 2,5
60 132 12 11 0 224 16 14 -1
90 100 10 10 -5 196 14 14 -7
20 90 100 10 10 -5 225 15 15 -7,5
8 2,5 15 96 12 8 3 187 17 11 4
5 15 84 12 7 4,5 187 17 11 5
30 88 11 8 3 165 15 11 3,5
45 63 9 7 1,5 120 12 10 1,5
60 56 8 7 -0,5 90 10 9 -0,5
90 49 7 7 -3,5 81 9 9 -4,5
10 60 64 8 8 1,5 132 12 11 0
90 64 8 8 -4 100 10 10 -5
(The mounting height is the distance from the reception plane and not from the floor).
Nr = Numberof carriers
H = mounting height [m]
a = mounting angle [degrees]
A= area [m
2
]
L= length[m]
W= width [m]
X= offset [m]
