LBB 4511/00 at full power LBB 4512/00 at full power
Nr. H a A L W X A L W X
45 1287 39 33 5 2107 49 43 5
60 990 33 30 -2 1677 43 39 -3
90 900 30 30 -15 1296 36 36 -18
33 45 1656 46 36 10 3038 62 49 8
60 1404 39 36 0 2392 52 46 -3
90 1089 33 33 -16 2116 46 46 -23
66 90 1089 33 33 -16 2401 49 49 -25
8 8 15 1014 39 26 10 2016 56 36 13
16 15 897 39 23 15 2016 56 36 16
30 936 36 26 10 1764 49 36 11
45 690 30 23 5 1287 39 33 5
60 598 26 23 -2 990 33 30 -2
90 529 23 23 -11 900 30 30 -15
33 60 676 26 26 5 1404 39 36 0
90 676 26 26 -13 1089 33 33 -16
(The mounting height is the distance from the reception plane and not from the floor).
Nr = Numberof carriers
H = mounting height [ft]
a = mounting angle [degrees]
A= area [ft
2
]
L= length[ft]
W= width [ft]
X= offset [ft]
