LBB 4511/00 at full power LBB 4512/00 at full power
Nr. H a A L W X A L W X
45 99 11 9 1 168 14 12 1
60 90 10 9 -1 132 12 11 -1
90 64 8 8 -4 100 10 10 -5
10 45 120 12 10 3 234 18 13 2
60 108 12 9 0 195 15 13 -1
90 100 10 10 -5 144 12 12 -6
20 90 64 8 8 -4 196 14 14 -7
8 2.5 15 84 12 7 2 160 16 10 3
5 15 60 10 6 4 144 16 9 4
30 70 10 7 3 140 14 10 3
45 63 9 7 1 99 11 9 1
60 49 7 7 0 90 10 9 -1
90 36 6 6 -3 64 8 8 -4
10 60 49 7 7 2 108 12 9 0
90 49 7 7 -3.5 100 10 10 -5
(The mounting height is the distance from the reception plane and not from the floor).
Nr = Numberof carriers
H = mounting height [m]
a = mounting angle [degrees]
A= area [m
2
]
L= length[m]
W= width [m]
X= offset [m]
