LBB 4511/00 at full power LBB 4512/00 at full power
Nr. H a A L W X A L W X
45 1080 36 30 3 1794 46 39 3
60 990 33 30 -3 1404 39 36 -3
90 676 26 26 -13 1089 33 33 -16
33 45 1287 39 33 10 2537 59 43 7
60 1170 39 30 2107 49 43 -3
90 1089 33 33 -16 1521 39 39 -20
66 90 676 26 26 -13 2116 46 46 -23
8 8 15 897 39 23 7 1716 52 33 10
16 15 660 33 20 13 1560 52 30 13
30 759 33 23 10 1518 46 33 10
45 690 30 23 3 1080 36 30 3
60 529 23 23 990 33 30 -3
90 400 20 20 -10 676 26 26 -13
33 60 529 23 23 7 1170 39 30 0
90 529 23 23 -11 1089 33 33 -16
(The mounting height is the distance from the reception plane and not from the floor).
Nr = Numberof carriers
H = mounting height [ft]
a = mounting angle [degrees]
A= area [ft
2
]
L= length[ft]
W= width [ft]
X= offset [ft]
92 en | Technical Data Language Distribution System
2013.11 | V1.4 | Operation manual Bosch Security Systems B.V.
