Connect HMV01.1R-W0120 supply units to the mains via an exter‐
nal mains contactor. The connection X40 receives the message
signals on the status of the external mains contactor (see also
chapter “X40, Acknowledge Messages of External Mains Contac‐
tor” ).
Description of the Connection Points
The connection points are described in detail in chapter 8 Functions and Elec‐
trical Connection Points , page 241.
Touch Guard
The touch guard is described in detail in chapter 9 Touch Guard at Devices ,
page 291.
7.4 HMV02.1R Supply Units, Regenerative
7.4.1 Brief Description, Usage and Structure
Brief Description
HMV supply units supply modular HMS and HMD devices.
Usage
The different types can be used as follows:
Type Usage
HMV02.1R
regenerative
to supply HMS02 drive controllers
Fig.7-47: Usage of supply units
222/369 Bosch Rexroth AG | Electric Drives
and Controls
Rexroth IndraDrive | Project Planning Manual
IndraDrive M Supply Units
