Distances
CAUTION
Property damage due to temperatures higher than 105 °C!
Comply with indicated minimum distances!
A air intake
B air outlet
C mounting surface in control cabinet
d
top
distance top
d
bot
distance bottom
Fig.7-57: Air intake and air outlet at drive controller
Basic Data Supply Unit HMV02, Regenerative
General Information
This chapter contains data with regard to:
● control voltage supply
● mains voltage supply
● DC bus
● built-in braking resistor or requirements on an external braking resistor
● cooling and power dissipation
The order of the data tables below follows the energy flow in the
supply unit - from mains connection to DC bus output.
Project Planning Manual | Rexroth IndraDrive Electric Drives
and Controls
| Bosch Rexroth AG 229/369
IndraDrive M Supply Units
