Identification
Type Plate Arrangement
1 power section type plate
2 control section type plate
Fig.5-48: Type plate arrangement
Type Plate
1 device type
2 part number
3 serial number
4 bar code
5 country of manufacture
6 production week, 04W12 meaning year 2004, week 12
7 hardware index
Fig.5-49: Type plate - power section (example of an HCS02 power section)
5.3.3 Scope of Supply
The scope of supply of the HCS03 power section includes:
● 1 × touch guard
● 1 × connector X3 (only for design W0070)
66/369 Bosch Rexroth AG | Electric Drives
and Controls
Rexroth IndraDrive | Project Planning Manual
Power Sections for Converters - IndraDrive C
